Deye SUN-120-136kW-G01P3-EU-AM8

  • 微信截图_20241017144259.png
  • 微信截图_20241018144418.png
  • 微信截图_20241018144400.png
  • 微信截图_20241018144409.png
    • 1
    • 2
    • 3
    • 4
8 MPP trackers, Max. effiffifficiency up to 98.8%
Zero export application, VSG application
String intelligent monitoring (optional)
Wide output voltage range
Anti-PID function (Optional)
Type II DC/AC SPD
ItemSolar Inverter
Place of OriginChina
Brand NameDeye
Model NumberSUN-120-136kW-G01P3-EU-AM8
Input Voltage1100V
Output Voltage220/380V, 230/400V 0.85Un-1.1Un
Output Current181.9-206.1A
Output Frequency50/45-55, 60/55-65
Size1006mm*516mm*325.5mm
Battery TypeRemote control+optical control
Inverter Efficiency98.7%
 CertificateIEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Warranty5 years
Weight103kg
Inverter TopologySolar Power System, Home/Commercial/Factory
ProtectionIP67
CommunicationGPRS/WIFI/Bluetooth/4G/LAN(optional)
Inverter typeThree phase
