Deye SUN-70-110kW-G03
Max. 6 MPP trackers, Max. efficiency up to 98.8%
Zero export application, VSG application
String intelligent monitoring (optional)
Wide output voltage range
Type II DC/AC SPD
Anti-PID function (Optional)
Zero export application, VSG application
String intelligent monitoring (optional)
Wide output voltage range
Type II DC/AC SPD
Anti-PID function (Optional)
| Item | Solar Inverter | ||||
| Place of Origin | China | ||||
| Brand Name | Deye | ||||
| Model Number | SUN-70-110kW-G03 | ||||
| Input Voltage | 1000V | ||||
| Output Voltage | 220/380V, 230/400V 0.85Un-1.1Un | ||||
| Output Current | 106.1-166.7A | ||||
| Output Frequency | 50/45-55, 60/55-65 | ||||
| Size | 824mm*516mm*312.7mm | ||||
| Battery Type | Remote control+optical control | ||||
| Inverter Efficiency | 98.7% | ||||
| Certificate | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | ||||
| Warranty | 5 years | ||||
| Weight | 81 | ||||
| Inverter Topology | Solar Power System, Home/Commercial/Factory | ||||
| Protection | IP67 | ||||
| Communication | GPRS/WIFI/Bluetooth/4G/LAN(optional) | ||||
| Inverter type | Three phase | ||||
